875192 |
Gasket set complete, AQ200/250/270/270T/275,A/280/280T/290
|
|
|
 |
875741 |
Gasket set complete, for AQ250/270/275280/290 with DP lower gear
|
|
|
 |
876266 |
Gasket set upper AQ200, 250, 270, 280, 285, 290, 290DP et. al.
|
|
|
 |
876268 |
Gasket set lower drive unit 200, 250, 270, 280, 285, 290, 290DP et. al.
|
|
|
 |
876536 |
Shield, AQ drives 250/270/275/A/280 (to order only)
|
|
|
 |
839377 |
Steering fork, AQ270 (MO-XXXX/80274) (to order only)
|
|
|
 |
839441 |
Steering fork, AQ270 (MOXXXX/80275-) (to order only)
|
|
|
 |
914169 |
Grease nipple, PV upper inner (45 degree)
|
|
|
 |
814359 |
Rubber sealing ring (V-ring)
|
|
|
 |
839195 |
V-ring (inner diam = 36 mm later production)
|
|
|
 |
814640 |
Bushing
|
|
|
 |
897731 |
Bushing AQ250, AQ270
|
|
|
 |
853861 |
Bushing connecting components, AQ270/AQ270T/280/T/290
|
|
|
 |
853048 |
Bushing for pivot pin AQ280, AQ290/A, AQ290DP, SP-A, SP-A1, SP-A2 +more
|
|
|
 |
854224 |
Sign "Volvo Penta" on AQ stern drive 250, 270, 275, 280, 290A
|
|
|
 |
804269 |
Screw
|
SP
|
|
 |
897745 |
Gasket
|
|
|
 |
852705 |
Pivot pin for 2 bolts, AQ280, 290, 290A, 290DP, SP-A/A1/A2, SP-C, SP-E, DP-A1/A2 etc
|
|
|
 |
941807 |
Bolt
|
|
|
 |
956568 |
Allen bolt for bearing holder AQ drive 100 (6/unit)
|
|
|
 |
897726 |
Rubber seal for shield AQ200/250/270T/275/280T
|
|
|
 |
925256 |
O-ring
|
|
|
 |
876631 |
Bellows kit (without ) AQ200/250/270/275/280/280DP/290/290DP
|
|
|
 |
832598 |
Zinc anode AQ drive 250 (late), 270, 275, 280, 280DP, 280PT, 285SP-A/MT
|
|
|
 |
832598-1 |
Aluminium anode AQ drive 250 (late), 270, 275, 280, 280DP, 280PT, 285SP-A/MT
|
|
|
 |
814301 |
Setting pin with fittings (stainless) AQ200/250/270/270T/275/275A/280L,T,DP, 285A, 290A, DP)
|
|
|
 |
941885 |
Nyloc nut (stainless)
|
|
|
 |
853175 |
Bearing pin flywheel casing AQ200 to 290
|
|
|
 |
873048 |
Clamping ring AQ, DPH, DPR all models (replaces 806310)
|
|
|
 |
804190 |
Seal ring flywheel housing AQ drive (outer, 200mm) (for engines w/o forward support - 2 req'd) )
|
|
|
 |
191844 |
Bolt kit for clamping ring
|
|
|
 |
806624 |
Lock plate flywheel casing (3 pcs required)
|
|
|
 |
875531 |
Rubber cushion for shield, AQ270/T, AQ280/T AQ280DP, SP-A
|
|
|
 |
832565 |
Gasket
|
|
|
 |
950364 |
Nut
|
|
|
 |
940097 |
Washer
|
SP
|
|
 |
950352 |
Lock nut (1/4" - 20 UNC)
|
|
|
 |
955893 |
Washer
|
SP
|
|
 |
875822 |
Hose kit AQ stern drives 200/250/270/275/280 + 280DP/280PT/285/285A/290DP/SP-A/MT
|
|
|
 |
839091 |
Hose, AQ drives 250/270/T/280/T/290
|
|
|
 |
850418 |
O-ring
|
|
|
 |
190878 |
Washer
|
SP
|
|
 |
940176 |
Nut
|
SP
|
|
 |
832941 |
Shaft, AQ drives 250/270/280/290
|
|
|
 |
11013 |
Rear bearing. M30/M40 -'66 + o/drive J (Koyo - Made in Japan)
|
SP
|
|
 |
914533 |
Circlip (better price with quantity)
|
SP
|
|
 |
914462 |
Circlip
|
SP
|
|
 |
941909 |
Spring washer, curved (I.d=11,5 mm)
|
SP
|
|
 |
940162 |
Bolt
|
|
|
 |
955535 |
Bolt
|
|
|
 |
952986 |
Exhaust hose AQ165, AQ170A/B/C
|
|
|
 |
854031 |
Water hose connection AQ200/250/270/280 +AQ280DP, AQ285A, AQ290, etc
|
|
|
 |
828693 |
Hose connection
|
|
|
 |
951789 |
Hose clamp 19-28 mm (for heater hoses)
|
SP
|
|
 |
994559 |
Hose clamp
|
|
